Introduction
1.2.4 Configuration and License PLUG (CLP)
Green
—
RM LED
The RM LED is associated with the Media Redundancy Protocol (MRP) feature. It
indicates if the device is a Media Redundancy Manager (MRM), or ring manager, in a
Media Redundancy Protocol (MRP) ring.
Note
MRP is not currently supported in SINEC OS. Feature support will be added in a future
release.
Green
Green
—
CM LED
The CM LED is associated with the Redundant Network Access (RNA) feature. It
indicates if the device is an HSR/PRP RedBox.
Note
RNA is not currently supported in SINEC OS. Feature support will be added in a future
release.
Green
—
1.2.4

Configuration and License PLUG (CLP)

The Configuration and License PLUG (CLP) is a removable USB storage medium for
backing up and exchanging data, such as configuration files, system firmware, and
product licenses.
The CLP has a USB type C interface and can be used with the following devices that
have a corresponding interface:
•
•
10
LED color LED state
On
Off
LED color LED state
On
Flashing
Off
LED color LED state
On
Off
Siemens products
Personal computers (PCs), such as desktop PCs, tablet PCs, laptops, or
smartphones
Description
The device is receiving power.
The device is not receiving sufficient power.
Description
The device is an MRM, the ring is operating without errors,
and monitoring has been activated.
The device is an MRM. However, an interruption in the ring
has been detected.
The device is not an MRM.
Description
The device is an HSR/PRP RedBox.
The device is not an HSR/PRP RedBox.
Equipment Manual, 10/2023, C79000-G8976-1528-01
RUGGEDCOM RST2428P
