Introduction
1.2.4 Configuration and License PLUG (CLP)
—
During operation
Red
—
Power supply LEDs
The PS1 and PS2 LEDs indicate status of the corresponding power supply.
These LEDs only illuminate during operation, not during startup.
The meaning of each LED is as follows:
LED color
—
Green
ACO button
The Alarm Cut-Off (ACO) button clears alarms and turns off the A LED.
1.2.4

Configuration and License PLUG (CLP)

The Configuration and License PLUG (CLP) is a removable USB storage medium for
backing up and exchanging data, such as configuration files, system firmware, and
product licenses.
The CLP has a USB type C interface and can be used with the following devices that
have a corresponding interface:
•
•
Position
The CLP slot is located below the status panel.
8
LED color LED state
Off
LED color LED state
On
Off
State
Off
On
Siemens products
Personal computers (PCs), such as desktop PCs, tablet PCs, laptops, or
smartphones
Device startup was completed successfully.
One or more active alarms.
No active alarms.
No external power supply connected.
An external power supply is connected and powered.
Description
Description
Description
RUGGEDCOM RST2228
Equipment Manual, 10/2023, C79000-G8976-1359-19
