Installing the device
2.3 Mounting the device
2.
3.
24
Mounting bracket
1
Screw
2
Figure 2.2 Installing the mounting brackets
Place the device against the panel and align the brackets with the mounting
holes.
1
2
Screw
1
Mounting bracket
2
Figure 2.3 Panel mounting
Secure the brackets to the panel using two pan head screws per bracket.
1 2
