Unpacking The Device; Mounting The Device - Siemens SIMATIC NET RUGGEDCOM RST2428P Equipment Manual

3.
4.
5.
6.
7.
8.
9.
2.2

Unpacking the device

When unpacking the device, do the following:
1.
2.
3.
Note
If any item is missing or damaged, contact Siemens for assistance.
2.3

Mounting the device

The device can be mounted to a panel or standard 48 cm (19 in) rack.
RUGGEDCOM RST2428P
Equipment Manual, 10/2023, C79000-G8976-1528-01
The "RUGGEDCOM Modules Reference Manual" [https://
support.industry.siemens.com/cs/ww/en/ps/29634/man]
https://support.industry.siemens.com/cs/ww/en/ps/29634/man.
Unpack and inspect the device.
For more information, refer to "Unpacking the device" (Page 21).
Mount the device.
For more information, refer to "Mounting the device" (Page 21).
Connect the failsafe alarm relay.
For more information, refer to "Connecting the failsafe alarm
relay" (Page 25).
Connect power to the device and ground the device to safety Earth.
For more information, refer to "Connecting power" (Page 28).
Secure all wires.
Secure all wires from the terminal blocks so they cannot be disturbed by casual
contact. For example, in rack mount installations, use tie wraps to secure the
wires to the rack.
Connect the device to the network.
For more information, refer to "Communication ports" (Page 49).
Configure the device.
For more information, refer to "Configuring the device" (Page 57).
Inspect the package for damage before opening it.
Visually inspect each item in the package for any physical damage.
Verify all items are included.
Installing the device
2.2 Unpacking the device
is available on SIOS at
21
