Available power modules
For a list of available power supply modules, including technical specifications and
ordering information, refer to the
support.industry.siemens.com/cs/ww/en/ps/29634/man].
Required tools/hardware
#1 Phillips screwdriver
Slotted screwdriver
AC/DC power cord
7 POS power terminal block plug
10-18 AWG multipurpose crimping tool
M3.5 (#6) ring tongue
Terminal block
A single terminal block provides power to both power supply modules. The terminal
block requires a 7 POS European-style (Euroblock) or screw-type terminal block plug.
Separate positive, chassis ground, and negative terminals are available for each
power supply module on the same terminal block plug.
RUGGEDCOM RST2428P
Equipment Manual, 10/2023, C79000-G8976-1528-01
Tool/hardware
"RUGGEDCOM Modules Reference Manua"l [https://
Quantity
1 For removing/installing screw-type
terminal block plugs and the terminal
block cover.
1 For removing/installing European-style
(Euroblock) terminal block plugs.
1 per power supply For connecting power to a power
supply module.
For the required wire gauge, refer
to the power supply specifications
in the
Reference Manua"l [https://
support.industry.siemens.com/cs/ww/
en/ps/29634/man].
1 Device includes one European-style
(Euroblock) or screw-type terminal
block plug.
Additional plugs are also available for
purchase. For more information, refer
to "Parts and accessories" (Page 17).
1 For stripping and crimping wires.
3 per power supply Only for screw-type terminal block
plugs.
Must have short insulated ring
terminals with a minimum distance of 5
mm (0.2 in) from the ring center to the
insulation.
Installing the device
2.5.3 Connecting main power
Detail
