Siemens SIMATIC NET RUGGEDCOM RST2428P Equipment Manual page 17

Introduction
1.2.3 Status panel
Yellow
a
1 period ≙ 2.5 seconds
Display mode B
In display mode B, the port LEDs indicate the transmission speed.
Note
Ports configured to auto-negotiate their settings with their link partners will turn off
when a connection error occurs. If auto-negotiation is disabled and a connection
error occurs, the port LED will continue to display the set transmission speed.
—
Green
Green
Yellow
Yellow
Yellow
a
1 period ≙ 2.5 seconds
Display mode C
In display mode C, the port LEDs indicate the duplex mode.
—
Green
Display mode D
In display mode D, the port LEDs indicate whether the port is monitored.
—
Green
Yellow
Alarm LED
The A LED indicates when an alarm condition exists.
8
LED color
Flashing
LED color
Off
On
Flashes once per period
On
Flashes twice per period
Flashes five times per period
LED color LED state
Off
On
LED color LED state
Off
On
On
LED state
LED state
a
a
a
The port is operating in half duplex mode.
The port is operating in full duplex mode.
The port is not monitored.
The port is monitored for changes to its "link up" state.
Error handling is triggered when the port changes to an
active state.
If a link has been established at the port, but it should not be
available, an alarm is generated.
The port is monitored for changes to its "link down" state.
Error handling is triggered when the port changes to an
inactive state.
If no valid link has been established at the port (e.g. the link
partner is switched off or the cable is not connected), an
alarm is generated.
Description
The port is receiving data.
Description
Port operating at 10 Mbps
Port operating at 100 Mbps.
Port operating at 10 Gbps.
Port operating at 1 Gbps.
Port operating at 2.5 Gbps.
Port operating at 2.5 Gbps.
Description
Description
RUGGEDCOM RST2428P
Equipment Manual, 10/2023, C79000-G8976-1528-01
