1.2.2 Orientation options
1.2.2
Orientation options
The following orientation options are available at the time of purchase:
•
•
1.2.3
Status panel
The status panel displays the real-time status of the device.
1
2
4
5
1
2
3
4
6
Option 1
Status panel, buttons, and ports are located on the front panel.
Figure 1.3
RUGGEDCOM RST2428P (Front panel orientation)
Option 2
Status panel, buttons, and ports are located on the rear panel.
Figure 1.4
RUGGEDCOM RST2428P (Rear panel orientation)
LEDs for 10GBase SFP+ transceivers (slot 0)
Module slot locators
LEDs for module ports
Status and mode LEDs
3
Equipment Manual, 10/2023, C79000-G8976-1528-01
RUGGEDCOM RST2428P
