Introduction

The RUGGEDCOM RST2428P is a utility grade, fully managed, industrial Ethernet
switch designed to operate reliably in harsh environments. With a rugged metal
enclosure and an optional conformal coating, the RUGGEDCOM RST2428P provides
a high level of immunity to electromagnetic interference and heavy electrical surges,
and can withstand extreme temperatures.
Highly modular, the RUGGEDCOM RST2428P switch supports up to 24 PoE ports
and 28 optical interfaces with data transfer rates of 10/100/1000 Mbps. Four ports
include data transfer rates of 10 Gbps. This makes it the ideal industry-standard
switch for constructing electrical and/or optical line, ring, and star topologies.
The RUGGEDCOM RST2428P switch is supported by RUGGEDCOM SINEC OS, which
provides advanced Layer 2 networking functions, and advanced cyber security
features.
1.1

Feature highlights

Power over Ethernet (PoE)
Note
The PoE feature is not supported by the current release of SINEC OS. Support will be
added in a future release.
•
•
•
•
•
•
•
•
•
Extreme flexibility
•
•
RUGGEDCOM RST2428P
Equipment Manual, 10/2023, C79000-G8976-1528-01
Supports up to 24 PoE ports with data transfer rates of 10/100/1000 Mbps
Supports 4-pair, up to 60 W of PoE power/port
Supports up to 120 W of PoE power/module (e.g. two 60 W ports or four 30 W
ports)
Supports up to maximum 500 W per system
Data and power over a single Ethernet cable
No mid-span patch panel required
Compatible with IEEE 802.3af, IEEE 802.3at, and IEEE 802.3ab powered devices
Auto-sensing ports that provide power only to PoE end devices
Power to port is turned off if cables are removed
Hot swappable media modules
Support for up to a total of 28 non-blocking ports (six 4-port modules and four
fixed ports)
