4.2

IP address assignment

An IP address must be assigned to the device to access the command line and Web
interfaces. The device is not assigned an IP address by default.
During initial commissioning, use one of the following methods to assign an IP
address to the device:
4.3

Configuring the device

Once the device is installed and connected to the network, it must be configured. All
configuration management is done via SINEC OS.
For more information, refer to the
support.industry.siemens.com/cs/ww/en/ps/29634/man]
software release.
RUGGEDCOM RST2428P
Equipment Manual, 10/2023, C79000-G8976-1528-01
Connect the device to a DHCP server
The device is configured by default to connect with a DHCP server. Once
connected, an IP address is assigned automatically.
For more information, refer to the
support.industry.siemens.com/cs/ww/en/ps/29634/man].
Set an IP address with SINEC PNI
Use the SINEC PNI (Primary Network Initialization) tool to manually assign a static
IP address to the device. Requires a Windows PC and Ethernet connection.
For more information, refer to
ps/26672.
Set a static IP address through a serial connection
1.
Connect a PC to the USB serial console port and establish a serial connection
with a terminal emulator, such as PuTTy or Tera Term.
For more information, refer to "Connecting to the device" (Page 55).
2.
Through the SINEC OS command-line interface, override the default
configuration for VLAN1 and assign a static IPv4 address.
For example:
localhost# config
Entering configuration mode terminal
localhost(config)# interface vlan1
localhost(config-interface-vlan1)# no ipv4 dhcp
localhost(config-interface-vlan1)# ipv4 address 192.168.10.33 pre
fix-length 24
localhost(config-address-192.168.10.33)# commit
Commit complete.
"SINEC OS Configuration Manuals" [https://
https://support.industry.siemens.com/cs/ww/en/
" SINEC OS Configuration Manual" [https://
Device management
4.2 IP address assignment
associated with the installed
57
