Introduction
1.5 Required tools/hardware
1.5 mm (1/16 in) Allen key
10-18 AWG multipurpose crimping tool
Hardware
AC/DC power cord
Mounting brackets
M3-0.5 x 5 mm flat head screws
Pan head mounting screws
6 POS power terminal block plug
7 POS power terminal block plug
M3.5 (#6) ring tongue
Braided or equivalent ground wire
16
Tools
Tools
1 per power supply For connecting power to a power
Quantity
1
For removing/installing the power
supply module set screw.
1
For stripping and crimping wires.
Quantity
supply module.
For the required wire gauge, refer
to the power supply specifications
in the
"RUGGEDCOM Modules
Reference Manua"l [https://
support.industry.siemens.com/cs/ww/
en/ps/29634/man].
4
Included with the device or available
as part of a separate mounting kit. For
more information, refer to "Parts and
accessories" (Page 17).
8
For securing the mounting brackets to
the device.
Included with the device or available
as part of a separate mounting kit. For
more information, refer to "Parts and
accessories" (Page 17).
8
For securing the mounting brackets to
the rack or panel.
1
For PoE power and the failsafe
alarm relay. The device includes one
European-style (Euroblock) or screw-
type terminal block plug.
Additional plugs are also available for
purchase. For more information, refer
to "Parts and accessories" (Page 17).
1
For HI ACDC or LO DC main power
connections. The device includes one
European-style (Euroblock) or screw-
type terminal block plug.
Additional plugs are also available for
purchase. For more information, refer
to "Parts and accessories" (Page 17).
4
For connecting wires to a screw-type
terminal block plug or the chassis
ground connection.
Except for the chassis ground
connection, the ring tongue must have
short insulated ring terminals with a
minimum distance of 5 mm (0.2 in)
from the ring center to the insulation.
1
For grounding the device to safety
Earth.
Equipment Manual, 10/2023, C79000-G8976-1528-01
