Orientation options

The following orientation options are available at the time of purchase:
•
•
1.2.3

Status panel

The status panel displays the real-time status of the device.
RUGGEDCOM RST2228P
Equipment Manual, 10/2023, C79000-G8976-1403-17
Option
RUGGEDCOM RMM2942-4LC2 (4 x 100MBit/s LC-interface, Optical: 100BASE-FX,
Multi Mode fiber optic up to 2 kilometer, 1310nm)
RUGGEDCOM RMM2972-4SFP (4 x SFP-slot, Supporting 100BASE-FX, 1000BASE-X
SFPs, SFPs are not included)
RUGGEDCOM RMM2973M-4RJ45 (4x RJ45 with MACsec, 10/100/1000 BASE-TX)
RUGGEDCOM RMM2972M-4SFP (4x SFP-slot with MACsec, Supporting 100BASE-FX,
1000BASE-X SFPs, SFPs are not included)
Option 1
Status panel, buttons, and ports are located on the front panel.
Figure 1.3 RUGGEDCOM RST2228P (Front panel orientation)
Option 2
Status panel, buttons, and ports are located on the rear panel.
Figure 1.4 RUGGEDCOM RST2228P (Rear panel orientation)
