Introduction
1.2.2 Orientation options
F11
Slot 6 options
G00
G01
G02
G05
G06
G10
G11
1.2.2

Orientation options

The following orientation options are available at the time of purchase:
•
•
6
Option
RUGGEDCOM RMM2972M-4SFP (4x SFP-slot with MACsec, Supporting 100BASE-FX,
1000BASE-X SFPs, SFPs are not included)
Option
RUGGEDCOM RMM2931-4 (Blank Module)
RUGGEDCOM RMM2973-4RJ45 ( 4 x RJ45, 10/100/1000 BASE-TX)
RUGGEDCOM RMM2973-4FC (4 x FastConnect (RJ45), 10/100/1000 BASE-TX)
RUGGEDCOM RMM2942-4LC2 (4 x 100MBit/s LC-interface, Optical: 100BASE-FX,
Multi Mode fiber optic up to 2 kilometer, 1310nm)
RUGGEDCOM RMM2972-4SFP (4 x SFP-slot, Supporting 100BASE-FX, 1000BASE-X
SFPs, SFPs are not included)
RUGGEDCOM RMM2973M-4RJ45 (4x RJ45 with MACsec, 10/100/1000 BASE-TX)
RUGGEDCOM RMM2972M-4SFP (4x SFP-slot with MACsec, Supporting 100BASE-FX,
1000BASE-X SFPs, SFPs are not included)
Option 1
Status panel, buttons, and ports are located on the front panel.
Figure 1.3 RUGGEDCOM RST2228 (Front panel orientation)
Option 2
Status panel, buttons, and ports are located on the rear panel.
Figure 1.4 RUGGEDCOM RST2228 (Rear panel orientation)
Description
Description
