Hardware Installation and Reference Guide
Aligning the AP with the mounting plate
Figure 3-6
Caution
Before buckling the master AP into the mounting plate, install the network cable first.
(3) In the opposite direction of the arrow on the mounting plate, push the master AP buckle into the
buckle hole from top to bottom to fasten it.
Buckling AP into mounting plate
Figure 3-7
DC power Or PoE
supply power supply
When wall-mounting the
master AP, keep the logo
"Ruijie" facing up.
21
Before buckling the master AP
into the mounting plate, install
the network cable first.
Installation
