- Page 1 Ruijie RG-SAP825-SP Access Point Hardware Installation and Reference Guide Document Version: V1.3 Date: 2023.09.26 Copyright © 2023 Ruijie Networks...
- Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
- Page 3 Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com ...
- Page 4 Specification An alert that contains a description of product or version support. 2. Note This manual provides the device installation steps, hardware troubleshooting, module technical specifications, and specifications and usage guidelines for cables and connectors. It is intended for the users who have some experience in installing and maintaining network hardware.
-
Page 5: Table Of Contents
Contents Preface ..............................I 1 Product Overview ..........................1 1.1 Appearance ..........................1 1.2 Package Contents........................3 1.3 Technical Specifications ......................3 1.3.1 Size and Weight ......................3 1.3.2 RF........................... 4 1.3.3 Ports ..........................5 1.3.4 Power Supply ......................... 6 1.3.5 Environment and Reliability ................... - Page 6 2.2.5 Cleanliness Requirements ................... 11 2.2.6 Anti-interference Requirements ................... 12 2.2.7 Lightning Protection Requirements ................13 2.2.8 Installation Site Requirements ..................13 2.3 Federal Communications Commission Statement ..............13 2.4 Tools ............................14 3 Installing the Access Point ......................15 3.1 Installation Flowchart .......................
- Page 7 4.1 Setting Up Configuring the Environment ................. 25 4.2 Powering up the AP ......................... 25 4.2.1 Checking Environment before Power-on ..............25 4.2.2 Checking Environment after Power-on ................ 25 5 Monitoring and Maintenance ......................26 5.1 Monitoring ..........................26 5.1.1 LED ..........................26 5.1.2 CLI Commands ......................
- Page 8 7.4 Power Supply ........................... 35...
-
Page 9: Product Overview
Product Overview Product Overview The RG-SAP825-SP AP is a dual-band dual-radio access point compliant with the IEEE 802.11ax standard. The RG-SAP825-SP AP provides a combined data rate of 2.976 Gbps, with up to 574 Mbps in the 2.4 GHz band and 2.402 Gbps in the 5 GHz band. Designed for flexible deployments in the field of education, government, finance and business, the RG- SAP825-SP AP offers one combo port. - Page 10 Hardware Installation and Reference Guide Product Overview Figure 1-2 Front Panel Table 1-1 Front Panel Item Description Indicate the operation status of device. Figure 1-3 Side View Table 1-2 Side View Button and Port Description...
-
Page 11: Package Contents
Connect to the DC power adapter to supply DC power plug power to the AP. Package Contents Table 1-3 Package Contents Item Quantity RG-SAP825-SP Access Point Mounting Bracket Wall Anchor Phillips Pan Head Screws M4 x 20 Warranty Card Installation Guide Technical Specifications 1.3.1... - Page 12 Hardware Installation and Reference Guide Product Overview Kensington lock Anti-theft Lock Security screw Bracket Dimensions 120 mm ×120 mm ×8 mm (4.72 in. x 4.72 in. x 0.31 in.) (W x D x H) Mounting Hole 53 mm (2.09 in.) x 53 mm (2.09 in.) Pattern Mounting Hole 6.5 mm (0.26 in.)
-
Page 13: Ports
Hardware Installation and Reference Guide Product Overview Max. Transmit 20 dBm (country-specific restrictions apply) Power Transmit Power Configurable in increments of 1 dBm Adjustment Modulation 802.11b：BPSK、QPSK、CCK 802.11a/g/n：BPSK、QPSK、16-QAM、64-QAM 802.11ac：BPSK、QPSK、16-QAM、64-QAM、256-QAM 802.11ax：BPSK、QPSK、16-QAM、64-QAM、256-QAM、1024-QAM 11b: -96dBm(1Mbps), -93dBm(5Mbps), -89dBm(11Mbps) 11a/g: -91dBm(6Mbps), -85dBm(24Mbps), -80dBm(36Mbps), - 74dBm(54Mbps) 11n: -90dBm@MCS0, -70dBm@MCS7, -89dBm@MCS8, - 68dBm@MCS15 Receive 11ac: 20MHz: -88dBm(MCS0), -63dBm(MCS9) -
Page 14: Power Supply
Hardware Installation and Reference Guide Product Overview Fixed Management One RJ45 Console port Port One system status LED Button One reset button 1.3.4 Power Supply Table 1-7 Power Supply Item Description Power Supply DC power adapter: 48 V/0.6 A (Optional. Please refer to Power Supply for more details.) PoE: IEEE 802.3af-compliant Max. -
Page 15: Leds And Button
Hardware Installation and Reference Guide Product Overview LEDs and Button Table 1-9 Fit AP State Frequency Meaning The AP is NOT receiving power or the AP is in Do Not Disturb mode, which can be disabled by software. Blinking green uBoot program initialization is in progress. -
Page 16: Sfp Modules
Hardware Installation and Reference Guide Product Overview SFP Modules The 2.5G SFP port of the AP supports both copper and fiber links. The negotiation speed may vary with the SFP module type and the speeds on both sides of the link. Table 1-11 Negotiation Speed When Connected with SFP Port on Peer Device Negotiation Speed AP SFP Port... -
Page 17: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Note To avoid personal injury and device damage, carefully read the safety precautions before you install the device. The following safety precautions may not cover all possible dangers. 2.1.1 General Safety Precautions ... -
Page 18: Electric Safety
Hardware Installation and Reference Guide Preparing for Installation 2.1.3 Electric Safety Warning Improper or incorrect electric operations may cause a fire, electric shock, and other accidents, and lead to severe and fatal personal injury and device damage. Direct or indirect contact with high voltage or mains power supply via wet objects may cause fatal dangers. -
Page 19: Ventilation Requirements
Hardware Installation and Reference Guide Preparing for Installation 2.2.2 Ventilation Requirements Reserve sufficient space in front of the air vents to ensure normal heat dissipation. After various cables are connected, bundle the cables or place them in the cable management bracket to avoid blocking air inlets. -
Page 20: Anti-Interference Requirements
Hardware Installation and Reference Guide Preparing for Installation Table 2-1 Requirements for Dust Dust Unit Content Dust particles (diameter ≤ 0.5 μm) ≤1.4×10^7 Particles/m Dust particles (0.5 μm ≤ diameter ≤ 1 ≤7×10^5 Particles/m μm) Dust particles (1 μm ≤ diameter ≤ 3 ≤2.4×10^5 Particles/m μm) -
Page 21: Lightning Protection Requirements
Hardware Installation and Reference Guide Preparing for Installation Keep the device away from the grounding equipment or lightning and grounding equipment of the power device as much as possible. Keep the device far away from high-frequency current devices such as high-power radio transmitting station and radar launcher. -
Page 22: Tools
Hardware Installation and Reference Guide Preparing for Installation Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference. (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 23: Installing The Access Point
Hardware Installation and Reference Guide Installing the Access Point Installing the Access Point The RG-SAP825-SP AP must be fixed and installed indoors. Caution Before installing the device, make sure you have carefully read the requirements described in Chapter 2. Installation Flowchart... -
Page 24: Precautions
Hardware Installation and Reference Guide Installing the Access Point The installation position meets the temperature and humidity requirements of the device. The power supply and required current are available in the installation position. The Ethernet cable have been deployed in the installation position. ... -
Page 25: Installing The Access Point
Hardware Installation and Reference Guide Installing the Access Point Do not subject the device to high temperatures. Keep away from high voltage cables. Install the device indoors. Do not expose the device in a thunderstorm or strong electric field. ... - Page 26 Hardware Installation and Reference Guide Installing the Access Point (2) Align the square feet on the rear of the AP with the mounting holes on the bracket. Figure 3-3 Aligning the Square Feet with the Mounting Holes Caution Install the Ethernet cables before mounting the AP on the bracket. (3) Slide the AP onto the bracket in the opposite direction of the arrow on the mounting bracket until it clicks into place.
-
Page 27: Wall Mounting
Hardware Installation and Reference Guide Installing the Access Point 3.4.2 Wall Mounting (1) Drill four 6.5 mm (0.26 in.) diameter holes in the wall and 53 mm (2.09 in.) apart, with the arrow on the mounting bracket facing up. Tap wall anchors into the holes, and drive screws through the mounting bracket into the anchors to secure the bracket. -
Page 28: Securing The Access Point
Figure 3-7 Mounting the AP on the Bracket Caution When mounting the AP on the wall, keep the Ruijie logo pointed upwards. The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots. -
Page 29: Installing The Sfp Module
Hardware Installation and Reference Guide Installing the Access Point Figure 3-9 Mounting the AP on the Bracket Caution Install the Ethernet cables before mounting the AP on the bracket. Installing the SFP Module (1) Insert the SFP module. Figure 3-10 Inserting the SFP Module (2) Connect the fiber. -
Page 30: Removing The Access Point
Hardware Installation and Reference Guide Installing the Access Point Figure 3-11 Connecting the Fiber Removing the Access Point (1) If the AP is installed on the ceiling, hold the AP in your hands and slide it sideways and away from the bracket in the LAN port direction. Figure 3-12 Removing the Ceiling-mounted AP (2) If the AP is installed on the wall, hold the AP in your hands and push it upward and away from the bracket in the LAN port direction. -
Page 31: Connecting Cables
Hardware Installation and Reference Guide Installing the Access Point Connecting Cables Connect UTP/STP to the LAN/PoE port on the AP. See Appendix A for supported wiring of twisted pairs. Caution By default, baud rate is set to 9600, data bit 8, parity none, stop bits 1 and flow control none on the Console port of the AP. -
Page 32: Checking After Installation
Hardware Installation and Reference Guide Installing the Access Point 3.10 Checking after Installation 3.10.1 Checking Cable Connection Make sure the UTP/STP cable matches the interface type. Make sure cables are properly bundled. 3.10.2 Checking Power Supply Make sure all power ports are properly connected and compliant with safety requirement. ... -
Page 33: Verifying Operating Status
Hardware Installation and Reference Guide Verifying Operating Status Verifying Operating Status Setting Up Configuring the Environment Use a power adapter or PoE to power the AP. Setting up the Environment Verify that the AP is properly connected to the power source. ... -
Page 34: Monitoring And Maintenance
Hardware Installation and Reference Guide Monitoring and Maintenance Monitoring and Maintenance Monitoring 5.1.1 You can observe the LED to monitor the AP in operation. 5.1.2 CLI Commands You can run related commands on the command line interface (CLI) of the device to remotely monitor the configurations and status of the AP. -
Page 35: Troubleshooting
Hardware Installation and Reference Guide Troubleshooting Troubleshooting Universal Troubleshooting Process The device works abnormally after installation. Check whether installation is correct. Check whether the power supply is correctly connected. Check whether the indicators are normal. Check whether cable connections on ports are correct. -
Page 36: Indicator Remains Red For A Long Time
Hardware Installation and Reference Guide Troubleshooting 6.2.3 Indicator Remains Red for a Long Time If the indicator stays red for a long time, it means that the Ethernet port cannot be connected. Check the connection on the Ethernet port. 6.2.4 Indicator Remains Green for a Long Time The device needs to be initialized when it is powered on. -
Page 37: Appendix
Hardware Installation and Reference Guide Appendix Appendix Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX. Compliant with IEEE 802.3ab, 1000BASE-T requires Category 5e 100-ohm UTP or STP (STP is recommended) with a maximum distance of 100 meters (328 feet). 1000BASE-T requires all four pairs of wires be connected for data transmission, as shown in Figure 7-1. - Page 38 Hardware Installation and Reference Guide Appendix Figure 7-3 100BASE-TX/10BASE-T Connection...
-
Page 39: Mini-Gbic Modules
Hardware Installation and Reference Guide Appendix Mini-GBIC Modules We provide appropriate SFP modules (Mini-GBIC) modules according to the port types. You can select the module to suit your specific needs. The following models and technical specifications of some SFP modules are listed for your reference. Table 7-1 Models and Technical Specifications of the SFP Module Intensity of Intensity of... -
Page 40: Cabling Recommendations
Hardware Installation and Reference Guide Appendix Cabling Recommendations During installation, route cable bundles upward or downward along the sides of the rack depending on the actual situation in the equipment room. All cable connectors should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet. Power cords should be routed upward or downward beside the cabinet close to the location of the DC power distribution cabinet, AC power outlet, or lightning protection box. - Page 41 Hardware Installation and Reference Guide Appendix be protected with insulating bushings. ○ Use proper cable ties to bind cables together. Do not tie two or more cable ties to bind cables. ○ Cut off excess cable tie cleanly with no sharp edges after bundling cables, as shown in Figure B-2.
- Page 42 Hardware Installation and Reference Guide Appendix sources are unavoidable, use high-temperature cables instead. ○ When using screws to fasten cable lugs, the bolts or nuts shall be tightened and prevented from loosening, as shown in Figure 7-7. Figure 7-7 Fastening Cable Lugs 1.
- Page 43 Hardware Installation and Reference Guide Appendix Power Supply DC power adapter: Input voltage: 48 V Rated current: 0.6 A Technical Specifications of the DC Power Connector Inner Diameter Outer Diameter Depth Polarity Inner pole: positive 2.1 mm (0.08 5.5 mm (0.22 in.) 10 mm (0.39 in.) in.)
