Hardware Installation and Reference Guide

Ports and LED

Figure 1-2 Ports
Table 1-2 Ports
No. Ports
1 DC Connector
Ethernet/PoE
2
Port
3 Reset Hole
4 SFP Port
Description
48 V DC/1 A input
100/1000/2500Base-T Ethernet ports, PoE-capable
The Reset hole is near the Ethernet/PoE port.
Stick the pin to the Reset hole: Restart the access point.
Press and hold the pin to the Reset hole for more than 5 seconds:
Restore the access point to factory settings.
1000Base-X SFP port (The SFP transceiver is an optional accessory.)
3
Product Overview
