Step 6 Connect the cables to the module and secure it to the motherboard
using M2 screws.
Step 7 Attach the thermal pad to the corresponding IC positions on the
module and secure the heatsink using M3 button head screws.
Hardware Installation
UST510-52B-FL Series user's Manual
25
