UST510-52B-FL Series user's Manual
⚫
Storage
RAID 0/1 supported via2 x 2.5" SATA HDD/SSD drive, up to 9.5mm in height
◼
◼ RAID 0/1/5/10 supported via 4 x 2.5" SATA HDD/SSD, up to 9.5mm in height
◼
2 x mSATA(occupied 2 x PCI Express Mini Card slot)
⚫ Flexible I/O Window
◼
2 x Optional I/O kits via mPCIe interface
⚫ Indicator
◼ 1 x Green LED as indicator for PWR status
◼ 1 x Green LED as indicator for HDD active
◼ 2 x Green LED as indicator for programmable
⚫ Button
◼ 1 x Power button
◼ 1 x Reset button
⚫
Antenna
◼ 4 x SMA type connector openings for antenna
⚫ Watchdog Timer
◼ 1~255 seconds or minutes; up to 255 levels.
⚫ Power Supply
◼ Railway : Typical：24Vdc input
◼
Vehicle : 9 to 36Vdc input (Typical：24Vdc)
⚫
Operation Temperature
◼ -40 °C ~+70 °C (-40 °F ~ 158 °F), with W.T. SSD & Memory : Coffee Lake
(Operating temperature varies depending on the CPU model in us e.)
Note: The performance of the system might be adversely affected when operating
at a temperature above the system's limitation, which might cause heat
throttling and underclocking, or with an unrecommended processor.
⚫
Storage Temperature
◼ -40 °C ~+85 °C (-40 °F ~ 185 °F)
⚫ Humidity
◼
10% ~ 95% (non-condensation)
⚫ Vibration Endurance
◼ 3Grm with SSD (5-500Hz, X, Y, Z directions)
◼ 0.8Grm with HDD (5~500Hz, X,Y, Z directions)
⚫ Weight
◼ 4.16 kg (9.17lb ) without package (8RJ-2SATA)
◼
4.97 kg (10.95lb) without package (16RJ-4SATA)
◼ 4.76 kg (10.49kb) without package (8M12-4SATA)
◼
4.82 kg (10.62lb ) with package (8RJ-2SATA)
◼ 5.63 kg (12.41lb) with package (16RJ-4SATA)
◼ 5.42 kg (11.94lb) with package (8M12-4SATA)
4 Introduction
