Step 6 Remove the original antenna bracket and attach the RJ45 bracket to
the panel.
Step 7 Apply the thermal pad to the corresponding IC positions on the LAN
module, and then use M2 screws to install the LAN module AX92918
onto the motherboard.
Hardware Installation
UST510-52B-FL Series user's Manual
29
