Proline Promass 84 MODBUS RS485
Endress+Hauser
!
Note!
• The display returns to the function SETUP COMMISSIONING (1002) if you press the Q key combination during
parameter interrogation. The stored parameters remain valid.
• The "COMMISSIONING" Quick Setup must be carried out before another Quick Setup is run.
m
The "DELIVERY SETTINGS" option sets every selected unit to the factory setting.
The "ACTUAL SETTING" option accepts the units you previously configured.
n
Only units not yet configured in the current Setup are offered for selection in each cycle.
The unit for mass, volume and corrected volume is derived from the corresponding flow unit.
o
The "YES" option remains visible until all the units have been configured.
"NO" is the only option displayed when no further units are available.
p
The promt ony appears if a current output and/or pulse/frequency output is available.
Only the outputs not yet configured in the current Setup are offered for selection in each cycle.
q
The "YES" option remains visible until all the outputs have been configured.
"NO" is the only option displayed when no further outputs are available.
r
The "automatic parameterization of the display" option contains the following basic settings/factory settings:
YES Main line = Mass flow
Additional line = Totalizer 1
Information line = Operating/system condition
NO The existing (selected) settings remain.
s
The execution of other Quick Setups are described in the following chapters.
Commissioning
55
