Proline Promass 84 MODBUS RS485
Material
Endress+Hauser
Transmitter housing:
• Compact version
– Compact version: powder coated die-cast aluminium
– Stainless steel housing: stainless steel 1.4301/ASTM 304
– Window material: glass or polycarbonate
• Remote version
– Remote field housing: powder coated die-cast aluminium
– Wall-mount housing: powder coated die-cast aluminium
– Window material: glass
Connection housing, sensor (remote version):
• Stainless steel 1.4301/304 (standard)
• Powder coated die-cast aluminum
(high-temperature version and version for heating)
Sensor housing / secondary containment:
• Promass F: acid-resistant and alkali-resistant external surface
– Stainless steel 1.4301/1.4307/304L
• Promass M: acid-resistant and alkali-resistant external surface
– DN 8 to 50: steel, chemically nickel-plated
– DN 80: stainless steel
• Promass A: acid-resistant and alkali-resistant external surface, stainless steel 1.4301/304
Process connections
Process connections, Promass F
Flanges according to EN 1092-1 (DIN 2501) /
according to ASME B16.5 / JIS B2220
DIN 11864–2 Form A (flat flange with groove)
Threaded hygienic connections
DIN 11851 / SMS 1145 / ISO 2853 / DIN 11864-1
Tri-Clamp (OD-tubes)
Process connections, Promass M
Flanges according to EN 1092-1 (DIN 2501) /
according to ASME B16.5 / JIS B2220
DIN 11864-2 Form A (flat flange with groove)
PVDF connection to DIN / ASME / JIS
Threaded hygienic connections
DIN 11851 / SMS 1145 / ISO 2853 / DIN 11864-1
Connector (high-pressure version)
Coupling (high-pressure version)
Process connections, Promass A
Mounting set for flanges EN 1092-1 (DIN 2501) /
ASME B16.5 / JIS B2220
Loose flanges
VCO coupling
Tri-Clamp (OD-tubes) (1/2")
Mounting set for SWAGELOK (1/4", 1/8")
Mounting set for NPT-F (1/4")
Material
Alloy C-22 2.4602/N 06022, stainless steel 1.4404/316L
Stainless steel 1.4404/316L
Stainless steel 1.4404/316L
Stainless steel 1.4404/316L
Material
Stainless steel 1.4404/316L, titanium grade 2
Stainless steel 1.4404/316L
PVDF
Stainless steel 1.4404/316L
Stainless steel 1.4404/316L
Stainless steel 1.4401/316
Material
Stainless steel 1.4539/904L, Alloy C-22 2.4602/N 06022
Stainless steel 1.4404/316L
Stainless steel 1.4539/904L, Alloy C-22 2.4602/N 06022
Stainless steel 1.4404/316L
Stainless steel 1.4404/316L
Stainless steel 1.4404/316L
Technical data
