Firewall

DMZ

If you have a client PC that cannot run an Internet application properly from behind
the NAT firewall, you can open the client up to unrestricted two-way internet access
by defining a virtual-DMZ (virtual-demilitarized-zone) host.

Figure 5-11 DMZ Settings

Enable – Enables the feature. (Default: Disabled)
IP Address of Virtual DMZ Host – Specifies the IP address of the virtual DMZ host.
(Range: 192.168.1.1 to 192.168.1.254; Default: 0.0.0.0)
Note: Adding a host to the DMZ may expose your local network to a variety of security
risks, so only use this option as a last resort.
Firewall
The OD200 provides extensive firewall protection by restricting connection
parameters to limit the risk of intrusion and defending against a wide array of
common hacker attacks. You can also block access to the Internet from clients on
the local network based on IP addresses and TCP/UDP port numbers, or specific
MAC addresses.

Figure 5-12 Firewall Setting

Enable – Enables the feature.
Disable – Disables the feature. (This is the default.)
5-11
