IDU Hardware Description
SIM Card Slot
The IDU also includes a standard SIM card slot that can be accessed by removing
the unit's top cover.
Some WiMAX service providers may require an optional SIM Card to be installed in
the IDU. The SIM card can include all required configuration details, including
security set up, operator information, and other end-user specific parameters.
The following figure shows the location of the SIM card slot under the top cover.
Pull top cover up until it snaps free
SIM Card
Location of SIM card slot
Figure 1-7 SIM Card Slot Access
1-9
