Chapter 2: Installing the OD200
This section describes how to install and connect the OD200 WiMAX Residential
Gateway.
Package Checklist
The OD200 package includes:
• ODU unit
• IDU unit
• ODU pole-mount bracket kit
• RJ-45 Category 5 network cable
• AC power adapter
• Quick Installation Guide
• Software Utilities and User Guide CD
Installation Overview
Before installing the OD200, verify that you have all the items listed in the package
checklist above. If any of the items are missing or damaged, contact your local
dealer. Also, be sure you have all the necessary tools and cabling before installing
the OD200.
Hardware installation of the OD200 involves these steps:
1.
Mount the ODU on a pole, mast, or tower using the mounting bracket.
2.
Install the IDU indoors.
3.
Connect the ODU-IDU Ethernet cable and a grounding wire to the ODU.
4.
Align the ODU antenna with the base station.
2-1
