Appendix B: Specifications

Physical Specifications

IDU Ports
4 LAN ports, 10/100BASE-TX with auto-negotiation, RJ-45 connector
2 FXS ports (PHONE1, PHONE2), RJ-11 connector
Network Interface
RJ-45 connector, auto MDI/X:
10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
LED Indicators
System: Power, WiMAX signal strength, WiFi
Ports: Link/Activity
AC Power Adapter
Input: 100-240 VAC, 50-60 Hz, 0.5 A
Output: 19 VDC, 3.4 A
Unit Power Supply
DC Input: 9~19 VDC, 2 A maximum
Power Consumption: 11 W maximum
Physical Size
169 x 184 x 80 mm (6.65 x 7.24 x 3.15 in)
Weight
x.x kg (x.x lbs)
Temperature
Operating: -5 to 45 °C (23 to 113 °F)
Storage: -40 to 75 °C (-40 to 167 °F)
Humidity
5% to 95% (non-condensing)
B-1
