Design and function

Welding torch connection

5.3
Welding torch connection
Fault with the wire guide!
On delivery, the central connector (Euro) is fitted with a capillary tube for welding
torches with spiral guides. Conversion is necessary if a welding torch with a plastic
core is used!
Welding torch with plastic core:
use with guide tube!
Welding torch with spiral guide:
use with capillary tube!
Preparation for connecting welding torches with a plastic core:
Push forward the capillary tube on the wire feed side in the direction of the central connector and
remove it there.
Slide plastic core guide tube off the central connector.
Carefully insert the central plug for the welding torch, with the still oversized plastic liner, into the
central connector and screw together with crown nut.
Use a suitable tool to cut off the plastic liner just before the wire feed roller, making sure not to pinch it.
Unfasten and remove the central plug on the welding torch.
Cleanly remove the burr from the separated end of the plastic core!
Preparation for connecting welding torches with a spiral guide:
Check that the capillary tube is correctly positioned in relation to the central connector!
40
NOTE
099-005172-EW501
21.09.2011
