Inside view

Control variants
• Machines with M1.xx control
There are additional control elements inside the machine for function control.
• Machines with M2.4x control
A "JOB list" label to define the welding tasks is attached to the inside of the casing
cover.
Item Symbol Description
1
2
3
4
5
6
7
099-005172-EW501
21.09.2011
Machine description – quick overview
0
Cover of the wire spool
Wire spool holder
Cover for wire feed unit and operating elements
Sticker, JOB List
Label, Wire feed parts subject to wear
Operating elements (see chapter Internal operating elements)
Wire feed unit
NOTE
Figure 4-3
Saturn drive 41L
