Machine description – quick overview
Saturn drive 41
4.2
Saturn drive 41
4.2.1
Front view
Item
Symbol Description
1
2
3
4
5
6
7
8
18
0
Carrying handle
Machine control
See Machine control – operating elements chapter
Machine feet
Operating / Connection element not used in this system!
Operating / Connection element not used in this system!
Central connection for welding torch (Euro)
Integrated welding current, shielding gas and torch trigger
Slide latch, lock for the protective cap
Recessed grip for opening the cap
Figure 4-4
099-005172-EW501
21.09.2011
