4.3.2.5

Welding parameter ignition time "tZn" diagram

In the ignition time, the wire feed continues to run at creep speed after the arc is ignited;
the ignition behaviour is improved with the optimum setting.
The process described below is always used if there is a pause between welding processes of
not less than 1.5 seconds.
Legend with an explanation of symbols can be found in the MIG/MAG function sequences /
operating modes chapter.
099-005172-EW501
21.09.2011
Machine description – quick overview
NOTE
Figure 4-10
Machine control – Operating elements
27
