6, If the calibration card can feel some resistance, it means
the nozzle height is proper. Enter the current value in the
red box on top to the red box in the middle, for example,
now the value is 205.40. Click the "OK" button to finish
the process.
Note: The normal gap between the tip of the nozzle and the build plate when printing is 0.2mm, which is the
thickness of the calibration card. For the material that is not easy to warp, the gap can be increased a little bit;
for the material that is easy to warp (shrink ratio is high), the gap should be decreased accordingly.
In order to avoid going through the nozzle height adjustment process frequently, users can set the "Offset" value
to adjust the nozzle height.
44
