5.4.2 Auto Calibration (UP Studio)
Click the "Calibration"
button in the UP Studio. A Calibration dialog will pop up.
9 Calibration Points on the build plate
Click "+/-" to move the print table UP or Down
Enter a value between "+" and "-" buttons as the
height of the print table, and click "MOVE" button,
the print table will move to the height specified.
Clicking the "Auto Level" button will trigger auto
calibration process and nozzle height adjustment.
Reset all the 9 point values to 0
This will trigger manual calibration and nozzle height
adjustment process
User can have the nozzle height value entered
here, and press Confirm to save
By clicking the buttons with numbers,
the extruder will move the point, and
the build table will move to the height
that equals to "Set nozzle height" +
"compensation"
37
