TierTime UP 300 Service Manual
  1. Manuals
  2. Brands
  3. TierTime Manuals
  4. 3D Printers
  5. UP300
  6. Service manual

TierTime UP 300 Service Manual

Hide thumbs Also See for UP 300:

Advertisement

Quick Links

Download this manual
UP 300 Service Manual
UP 300 Service Manual
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the UP 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TierTime UP 300

Summary of Contents for TierTime UP 300

  • Page 1 UP 300 Service Manual UP 300 Service Manual...
  • Page 2 Buzzer has no sound / low volume Software shows that the nozzle temperature or platform temperature is too high Failed to connect UP 300 (USB), USB transfer failed Failed to connect UP 300 (Wi-Fi), Wi-Fi transmission failed Failed to connect UP 300 (Wi-Fi)
  • Page 3 Print platform continues to heat up automatically The display does not work/works abnormally (no response when tapping an icon on the touch screen) Data transmission error 6/SD card error/repeated printing failure/unable to save and update high value Motion system error UP 300 Service Manual...
  • Page 4 Method of replacing nozzle PCB board, heating parts, nozzle parts Method of replacing Wi-Fi antenna, TF card, CPU, mainboard Method of replacing FFC-Y axis cable and Y-axis limit Method of replacing PCB-Y axis adapter board Method of replacing HEPA filter UP 300 Service Manual...
  • Page 5 Method of replacing Z-axis screw motor Method of replacing Z-axis limit Method of replacing 26P color cable Method of replacing screen power cable, signal cable, CFC-USB disk interface, SD card Method of replacing display, Wi-Fi component, USB disk interface board UP 300 Service Manual...
  • Page 6 Remove and ➢  CPU damaged Turn off the power and replace the CPU replace CPU ✓ Remove and ➢  Display damaged Turn off the power and replace the display replace display Back to Directory UP 300 Service Manual...
  • Page 7 Mainboard damaged Turn off the power and replace the mainboard replace turn off the power mainboard ✓ Remove and ➢  CPU damaged Turn off the power and replace the CPU replace CPU Back to Directory UP 300 Service Manual...
  • Page 8 Display damaged/ Turn off the power and replace the display Remove and replace display  ✓ Back to Director power/signal cable Check if the power/signal cable is disconnected or Remove and replace damaged broken power/signal cable UP 300 Service Manual...
  • Page 9 Y-axis back and forth five times to check if the belt has obvious displacement and wear ➢  Z axis abnormal Check if the 26P color cable with black net under sound the platform falls off UP 300 Service Manual Back to Directory...
  • Page 10 ✓ Remove and ➢  Turn off the power and replace the Mainboard replace damaged mainboard mainboard ⚫ No sound under any operation ⚫ Low volume under any operation Back to Directory UP 300 Service Manual...
  • Page 11 Printing stops and reports nozzle circuit temperature high temperature error error when ➢ Mainboard  Turn off the power and replace the ✓ Remove and replace loading model damaged mainboard mainboard Back to Directory UP 300 Service Manual...
  • Page 12 Failure 07: Failed to connect UP 300 (USB), USB transfer failed Failure Cause Solution Remark  Check if the USB cable is damaged (damaged, connector ➢ USB cable is not deformed), and re-plug the USB cable on the mainboard fixed/loose; USB...
  • Page 13 Solution Remark ➢ The wireless status  Restart the UP 300 and UP Studio software, and confirm that the of the connection display and PC are connected to the same Wi-Fi between the PC  If the workspace has multiple Wi-Fis for different purposes, its...
  • Page 14 Failure 9: Failed to connect UP 300 (Wi-Fi) Failure Cause Solution Remark ➢  The wireless Restart the UP 300 and UP Studio software, status of the and confirm that the display and PC are connection connected to the same Wi-Fi ...
  • Page 15 PC firewall settings email address, but the activation email ➢ Some email suffixes has not been  Replace with commonly used email for have limitation received registration (QQ, NetEase, 263, etc.) (e.g. .org) Back to Directory UP 300 Service Manual...
  • Page 16  Turn off the power and replace the mainboard damaged mainboard ✓ Remove and replace ➢ nozzle adapter  Remove and replace the nozzle adapter cable the nozzle adapter cable is broken cable Back to Directory UP 300 Service Manual...
  • Page 17 ✓ Remove and replace the Turn off the power and replace the nozzle assembly nozzle motor ✓ Remove and replace ➢  Mainboard damaged Turn off the power and replace the mainboard mainboard Back to Directory UP 300 Service Manual...
  • Page 18  Need to confirm with the IT code returned by the server does department of the factory not match the whether the serial number has printer’s check been uploaded to the cloud code Back to Directory UP 300 Service Manual...
  • Page 19 Software material material being used in the weight setting is wire box in the “Material” Software prompt improper interface of the UP Studio software ⚫ Error when transferring data model: material not enough, continue? Back to Directory UP 300 Service Manual...
  • Page 20 UP 300 when sending a print task  The forming space of UP 300 model and the error “Model out of is X*Y*Z=205mm*255mm*225mm print range” is reported when transmitting ➢...
  • Page 21 Remove and replace replace it if yes be printed the contact is nozzle CFC cable  Check if the CFC cable of the nozzle is poor damaged, and replace it if yes Back to Directory UP 300 Service Manual...
  • Page 22 X motor ➢  ✓ Motor of fault axis Turn off the power and replace the motor of the Remove and damaged fault axis replace Y motor ✓ Remove and Back to Directory replace Z motor UP 300 Service Manual...
  • Page 23 ➢  Disconnect during Ensure that the connection between the PC transferring data file and UP 300 is stable and the front door to UP 300 remains closed when the file is transferred ⚫ Pause during data transmission and report error: “Please close the front door of...
  • Page 24 Mainboard replace damaged mainboard in progress mainboard ✓ Remove and ➢ Platform  Turn off the power, replace the replace the adapter board is platform adapter board platform damaged adapter board Back to Directory UP 300 Service Manual...
  • Page 25 Remove and ⚫ The print model has surface ➢  Mainboard Turn off the power and replace the replace defects such as breakpoints damaged mainboard mainboard ➢  Material problem Replace with new materials Back to Directory UP 300 Service Manual...
  • Page 26 Remove and  Turn off the power and replace the mainboard Y-axis test method damaged replace mainboard ✓ Remove and ➢  CPU damaged Turn off the power and replace the CPU replace CPU Back to Directory UP 300 Service Manual...
  • Page 27 ➢ The size of the model base is  large, and the Set the filling to a looser option within the filling method software isn’t changed accordingly Back to Directory UP 300 Service Manual...
  • Page 28 Replace the ➢  Remove the rear panel and the Wire inspection limit ⚫ Pause automatically during wire damaged, falsely right side panel to replace the inspection printing connected wire inspection limit component Back to Directory UP 300 Service Manual...
  • Page 29 Up ➢ Software problem website, and re-transfer the print studio folder in the  http://www.tiertime.com old version of the  https://www.up3d.com installation directory Back to Directory UP 300 Service Manual...
  • Page 30 ➢Irregular texture position of the ✓ Replace the SD  Turn off the power and replace the SD card same model is always consistent; card caused by SD card Back to Directory UP 300 Service Manual...
  • Page 31  Turn off the power and replace the ⚫ The platform plate heating base plate automatically heats up after ✓ Remove and ➢  Turn off the power and replace the Mainboard initialization or replace damaged mainboard mainboard printing Back to Directory UP 300 Service Manual...
  • Page 32 ✓ Remove and ➢ Peripheral be powered on, but  Turn off the power and replace the peripheral replace the interface board the function is interface board peripheral damaged abnormal interface board Back to Directory UP 300 Service Manual...
  • Page 33 Turn off the power and replace the peripheral replace the interface interface board peripheral damaged interface board ✓ Remove and ➢  CPU damaged Turn off the power and replace the CPU replace CPU Back to Directo UP 300 Service Manual...
  • Page 34  Turn off the power and replace the Mainboard replace automatically damaged mainboard mainboard during printing ✓ Remove and ➢ Mainboard  Turn off the power and replace the replace adapter board mainboard adapter board mainboard damaged adapter board Back to Directory UP 300 Service Manual...
  • Page 35 6. Loosen the 6 screws marked in Fig. 6, and remove the left panel assembly. 平齐 Note: Please disassemble from step 1 to 6 and install in the reverse steps and pay attention to the fit between Back to the panels UP 300 Service Manual Directory...
  • Page 36 4. Remove and replace the mainboard adapter board; Note: For the installation direction of FFC cable, the side with metal contact should be on the same side as the internal metal contacts on the interface. Back to Directory UP 300 Service Manual...
  • Page 37 1. Use a cross screwdriver to remove the 4 screws of the adapter board cover and then remove the rear nozzle cover. 2. Pull out the 2 lines as shown in the figure. 3. Pull out the CFC-nozzle cable interface to remove and replace the PCB-nozzle adapter board. Back to Directory UP 300 Service Manual...
  • Page 38 2. Pull out the interface shown in the figure from the bottom to remove the height aligning board component; 3. Remove the screws fixing the height aligning board, push out the height aligning board in the direction shown, and then replace the PCB-height aligning board. Back to Directory UP 300 Service Manual...
  • Page 39 Note: Pay attention to the reserved length of the steering gear cable during installation, that is, the CFC cable touches neither the belt nor the steering gear board in the steering process of the steering gear. Back to Directory UP 300 Service Manual...
  • Page 40 2. If the operation is inconvenient during the disassembly process, remove the left shell first. For the disassembly method, see the disassembly and assembly of the shell; Method of removing the shell Back to Directory UP 300 Service Manual...
  • Page 41 2. Cut off the cable tie of the interior light wire, and then pull out the plug of the interior light in the mainboard. 1. Loosen the 6 screws of the interior light clip and loosen the cable tie. 2. Remove the interior light and replace it.。 cable buckle Back to Directory UP 300 Service Manual...
  • Page 42 3. Cut off the 2 cable ties of the machine’s internal door inspection cable, and then remove the door inspection cable; 4. Open the Hall switch clamp and replace it; paying attention to the direction of the Hall switch. Font face up Back to Directory UP 300 Service Manual...
  • Page 43 2. Remove 12 round rubber pads, then remove 12 screws and remove the front door frame; 3. Loosen the 2 screws that lock the magnet and then lift the magnet out to replace it. (Replace the magnet and apply some 496 glue) Back to Directory UP 300 Service Manual...
  • Page 44 3. Unscrew the four screws of the nozzle cover behind the nozzle holder; contact side of the interface. 4. Pull out the interface of the FFC nozzle cable on the PCB nozzle adapter board to remove the nozzle FFC. FFC cable folding length 83mm Back to Directory UP 300 Service Manual...
  • Page 45 2. After removing the nozzle cable cover, pull out the CFC nozzle cable as shown in the figure; 3. After removing the fixing screw at the lower left, remove the nozzle. (The removal method of TPU/PLA/ABS nozzle is the same) Back to Directory UP 300 Service Manual...
  • Page 46 2. When installing the nozzle cover, pay attention to the fact that the heating wire to fire prevention. Back to Directory can’t be caught in the lower right corner. UP 300 Service Manual...
  • Page 47 Note: The PLA nozzle is removed in the same way as the ABS nozzle, except that the heating element has one end cap and no Back to Directory grooved clamp is installed. UP 300 Service Manual...
  • Page 48 Back to Directory UP 300 Service Manual...
