Precautions 1. UP BOX 3D printer requires power adapter provided by original manufacturer. Otherwise machine could be damaged or even cause fire hardzard. Please also keep the power adapter away from water and high temperature. 2. During printing, the nozzle of the printer will reach 260...
Page 4
UP BOX Specification Printing Technology MEM (Melted Extrusion Manufacturing) Build Volume 255 x 205 x 205mm (W x H x D) 10" x 8" x 8" Print Head Single, Modular for easy replacement. Z-Resloution 0.1/0.15/0.20 /0.25 /0.30 /0.35 /0.40 mm...
Printer Body Top Lid Front Door Spool Holder Filament Spool Magnetic Cover Pause/Stop Button Extrude/Withdraw Button Initialization Button USB Interface Power Interface Power Switch...
Page 6
X-Axis Z-Axis Y-Axis Air Filter LED Bar Print Platform Print Head Print Head Mount Magnets Nozzle Automatic Leveling Probe Metal Plate...
Accessories Power Cable USB Cable Power Adapter Scraper 2.5mm Hex Keys Plier ABS Filament Nozzle Wrench Print Head Nozzle CD-ROM Perf Board *If anything is missing please contact your local distributor or support@pp3dp.com...
Page 8
Remove Nylon Ties Remove nylon ties from the horizontal smooth rods. Install Perf Board...
Install Filament To install the filament spool, open the magnetic cover and insert the filament into the guiding tube at the spool holder. Push filament into the guiding tube until it come out from the other end, put the spool onto the cassette and cover the spool with the magnetic cover.
Two ways of initialization: 1. UP BOX can be initialized by clicking initialization option in the menu which is shown above. 2. When the printer is idle, long press the initialization button on the printer will also trigger...
Page 11
(eg. slightly tilted platform) and this could cause warping of prints or even complete failure. Fortunately UP BOX has automatic platform calibration and automatic nozzle height detection functions. By using these 2 functions, the calibration process could be finished quickly and easily.
Page 12
Automatic Nozzle Height Detection Choose "Nozzle Height Detect" in 3D Print menu. The print head will move toward the nozzle height detection device and the nozzle will eventually touch and press the metal part on the device to make the meausrement. The detected nozzle height value wlll be stored in the in the machine.
Page 13
There are 3 screws under the platform of UP BOX. Two screws in front and one screw under the platform at the back. These screws can be fastened or loosened to adjust the leveling of the platform.
Page 14
Prepare for Printing Make sure printer switched on and connected to computer. Select Main Menu - 3D Print - Maintainance. Click New Spool and choose ABS and input filament weight. Click "Extrude" button, the print head will start to heat up, within 5 minutes its temperature will reach 260 C, then printer will...
Page 15
Initialize Reprint last job Printer LED Light Bar Different color and behavoiur of the "UP BOX" light bar indicate different status of printer. Breathing: Printer switched on, uninitialized. Breathing: Printer initialized, ready for printing. Single Letter Rotation: Data transfer and printing in progress.
Page 16
Software Interface Quick functional Buttons Main Menu Status Bar Display the statsu of printer and Print Plate software. - left mouse click and hold, moving mouse to adjust camera angle. - Right mouse click and hold, moving mouse to move print plate. -Mouse wheel could scale the print plate view.
Page 17
Loading a Model Click "Open" Choose your model. Loaded model on the print plate. Click "Print" to open the print preview window .
Page 18
Click "OK" to start printing. The program will process the model and then transfer the data to the printer. Af te r s en di n g th e d at a , the program will suggest the amount of material and time needed for the model in a pop up window.
Printing Progress Printing progress is shown in the LED progress bar on top of the UP BOX letters. The first two red LED represent printing of raft, the others represent the rest of the model. Pause of Print Job During printing, the machine could be paused through maintainence interface.
Page 20
Pause of Print Job without using Software During printing when the front door is opened, printing will be paused automatically. After closing the front door the print job will not be resumed until the user double click the pause button. Pause/Stop Button Alternatively, during Printing, double click the Extrude/Withdraw Button...
Moving Model Click the model to select. Click Move button. Select distance value to in the drop dwon menu. Choose an axial direction to move the model. Drag model with mouse on XY-plane: Press and hold Ctrl key, mouse left click and hold the target model, now the model could be dragged around on XY-plane.
Rotate Model Click to select model. Click Rotate button. Choose angle of rotation in the drop dwon menu. Choose an axial direction to rotation the model. Scale Model Click to select model. Click Scale button. Choose the scaling value in the drop down menu.
Duplicate Model Click to select model. After selection, right click to open menu In the insert copy m e n u, s e l e c t t h e number of copy for duplication. Right click menu also contain unload function. Either choose a specific model to unload or unload all.
Printing Parameters 1. Z-resolution: Thickness of each printed layer, the lower the value, the more details will be generated. 2. Part: Angle: Determine the range of dense support generation. Surface: Choose the how many layers will be made for bottom of the model. 3.
Annotation for printing parameters Dense (support) Infill Dense (support) Support Surface Dense (support) Print Platform Raft Suppot Range: Support Range: < 30 < 80 Dense: Solid support structure ensure the surface being supported retain its shape and surface finish. Infill: The inner structure of the printed object, the density of infill could be adjusted.
Repair Model UP software contains model repair function, could be used to fix simple defects. If the model contains defective surfaces. The sofware will highlight the part with red. A f t e r s e l e c t i n g t h e model, choose Edit - Fix to repair the model.
Calibration for the Correct Dimension If prints are too big or too small or skewed, user could re-calibrate the printer to print in correct dimension. The method is to print a calibration model, measure its dimension and feedback to the software. L o a d a n d p r i n t t h e calibration model: C : \ P r o g r a m F i l e s \ U P \...
Printing Techniques 1. Ensure accurate nozzle height. Nozzle height value too low will cause warping, too high will crash nozzle to platform causing damage and clogging. It is possible to manually fine tune nozzle height value at "maintenance" and "print preview" panels. User could try to adjust the nozzle height value plus or minus 0.1 - 0.2mm base on previous results.
Page 29
Maintenance Remove the nozzle. After a long time of printing, the nozzle could become very dirty or even clogged. We can replace it with a new one while the old one could be cleaned and reused. Nozzle Wrench 1. Use "Withdraw" function in the maintenance panel, nozzle will heat up to printing temperature.
Please use UP Fila filament. 4. For some model, if PLA consistently cause problem, switch to ABS. 1. Install the printer driver correctly. Cannot detect the printer 2. Check for defective USB cable. 3. Restart printer and Computer Contact technical support: Others support@tiertime.net...
Page 31
Appendix A - Fine Manual Calibration 1. Setting nozzle height. 2. Setting compensation values. Open: Menu - 3D Print - Platform Calibrate A. Moving Platform UP/DOWN: click/hold the button, platform will move accordingly. B. Display the current platform height. C. Setting nozzle height: click this will set the current platform height as the nozzle height.
Page 32
Hit the "5" button. Nozzle will go to the center of the platform. Raise the platform until it is just touching the nozzle. Move the paper between the nozzle and platform and see if there is any resistance. Platform too high, nozzle Just right, could feel Platform too low, no is pinning paper onto...
Page 33
Platform Values at 9 calibration points (hypothetical): When obtained the platform height value of all 9 positions. Find out the 1: 208 2: 208.5 3: 208.7 smallest value among the 9 calibration points. As you can see in this case, the calibration point 1 has the smallest 4: 208.6 5: 208.9...
Page 34
F o r e x a m p l e , s e t t i n g t h e compensation value for calibration point No.3. Assume the "platform height" is 208.7 and the "nozzle height" is 208, the compensation value should be set to 0.7.
Page 35
