- Page 1 UP mini user manual version ： 4.6.23...
-
Page 2: Table Of Contents
Table of Content Precautions .......................... 01 Printer Body illustration ....................03 Accessories .......................... 05 Installing the Print Head ....................06 Install the Perf Board ....................... 07 Install UP Software ......................08 Initialization of Printer ..................... 09 Platform Calibrate 1.Setting Nozzle Height ..................11 2.Setting Compensation Values .............. -
Page 3: Precautions
Precautions 1. UP mini 3D printer requires power adapter provided by original manufacturer. Otherwise it could casue damage to machine or even fire hardzard. Please also keep the power adapter away from water and high temperature. 2. During printing, the nozzle of the printer will reach 260 C and the print platform could reach C. - Page 4 UP mini Specification Technology MEM (Melted Extrusion Manufacturing) Build Volume 120x120x120mm Print Head Single, Modular for easy replacement. Z-resoution 0.2/0.25/0.3/0.35mm Printing Supporting Structure Automactically generated, easy to remove, adjustable Platform Leveling Manual Print Surface Heated bed with perf board Unterthered Printing...
-
Page 5: Printer Body Illustration
Printer Body illustration Top Lid USB Port Initialization Button Power Connector Front Door USB Port Spool Holder Power Switch Power Connector... - Page 6 Initialization Button Print Head Print Platform Y-Axis Print Head Nozzle Z-Aixs X-Axis...
-
Page 7: Accessories
Accessories USB Cable Power Adapter Perf Board Spool Holder ABS Filament Print Head Hex Key Filament guiding tube Plier Gloves Shovel Nozzle Wrench Blots and Nuts *If anything is missing please contact your local distributor or support@pp3dp.com... -
Page 8: Installing The Print Head
Installing the Print Head There are 3 During installation magnets for holding m a k e s u r e t h e the print head in magnets are aligned place. to the metal plates on the print head's stepper motor. After fitting the print head, plug in the cable to connector... -
Page 9: Install The Perf Board
Install the Perf Board Slide the perf Finsihed. board into the s l o t s o n t h e 2 sides of the platform. Install the Spool Holder Hook the spool holder on the back of the printer. Install Filament Spool As shown in the diagram, put the filament spool on the spool holder... -
Page 10: Install Up Software
Install UP software 1. Go to to download www.pp3dp.com the latest version of UP Software. 2. D o u b l e c l i c k U P ! S e t u p. e xe to install the software(default installation directory C:\Program a pop up window will... -
Page 11: Initialization Of Printer
XYZ aixs will move slowly and hit the endstops. This is essential as the printer need to find the endpoints of each axis. Two ways of initialization: 1. UP mini can be initialized by clicking initialization option in the menu which is shown above. Initialization Button 2. - Page 12 The other functions of Initialization Button: 1. Stop current print job:During printing press and hold the button. 2. Switch On/Off print head LED:Quick double hit of the button. Platform Calibration Plarform calibrate is the most important step for successfull printing, as it ensures the first layer adhesion.The actaual calibration is done by measuring the distance between the nozzle and platform.Ideally, the distance between nozzle and platform is constant, but in reality the distance varies at different position due to many reasons (eg.
-
Page 13: Platform Calibrate 1.Setting Nozzle Height
Platform Calibrate: 1.Setting Nozzle Height Setting nozzle height, actually, is not setting the nozzle itself as UP mini's print head does not move in the Z-axis. Here the nozzle height we are refering to is a platform height value, at this height, the platform will be just touching the nozzle (thus "nozzle height"). - Page 14 Platform Too high, nozzle Just right,could feel some Platfor m too low, no i s p i n n i n g p a p e r o n t o resistance when moving resistance at all when the platform, Lower the the paper.
-
Page 15: Setting Compensation Values
Platform Calibration: 2.Setting Compensation Values As shown in the left, when platform is at the "nozzle height", only part of the platform is touching the nozzle. Therefore we need to set compensation values for all other calibration points to inform the printer about the distance between nozzle and print sur face thorughout the XY plane. -
Page 16: Prepare For Printing
Prepare for Printing Make sure printer switched on and connected to computer. Select Main Menu - 3D Print - Maintainance. H it "Ex trude" button,the pr int head will start to heat up, within 5 minutes its temperature will reach C,then printer will buzz and the print head startts to extrude. -
Page 17: Loading A Model
Loading a model Click Load Choose your model. Loaded model on the print plate. Click print to open the print preview window. - Page 18 Click "OK" to start printing. The program will first slice the model into Gcode and then transfer the data to the printer. A f t e r s e n d i n g t h e d a t a , t h e program will suggest the amount of material and time needed for the model in a pop up window.
-
Page 19: Software Interface
Software Interface Quick functional Buttons Main Menu Status Bar Display the statsu of printer and Print Plate software. - left mouse click and hold, moving mouse to adjust camera angle. - Right mouse click and hold, moving mouse to move print plate. -Mouse wheel could scale the print plate view. -
Page 20: Moving Model
Moving Model Click to select model. C l i c k M o v e button. S e l e c t d i s t a n c e value to in the drop dwon menu. Choose an axial direction to move the model. -
Page 21: Rotate Model
Rotate Model Click to select model. C l i c k R o t a t e button. Choose angle of rotation in the drop dwon menu. Choose an axial d i r e c t i o n t o rotation the model. -
Page 22: Duplicate Model
Duplicate Model Click to select model. After selection, right click to open menu In the insert copy m e n u, s e l e c t t h e number of copy for duplication. Right click menu also contain unload function. Either choose a specific model to unload or unload all. -
Page 23: Printing Parameters
Printing Parameters 1. Z-resolution: Thickness of each printed layer, the lower the value, the more details will be generated. 2. Part: Angle: Determine the range of dense support generation. Surface: Choose the how many layers will be made for bottom of the model. -
Page 24: Annotation For Printing Parameters
Annotation for printing parameters Dense (support) Infill Dense (support) Support Surface Dense (support) Print Platform Raft Suppot Range: Support Range <30 <80 Dense: Solid support structure to ensure the surface being supported retain its shape and surface finish. Infill: The inner structure of the printed object, the density of infill could be adjusted. -
Page 25: Repair Model
Repair Model UP software contains model repair function, can be used to fix simple defects. If the model contains defects, eg.have holes. The sofware will highlight the part with red. A f t e r s e l e c t i n g t h e model, choose Edit - Fix to repair the model. -
Page 26: Calibration For The Correct Dimension
Calibration for the Correct Dimension If prints are too big or too small or skewed, user could re-calibrate the printer to print in correct dimension. The method is to print a calibration model, measure its dimension and feedback to the software. L o a d a n d p r i n t t h e calibration model: C : \ P r o g r a m F i l e s \ U P \... -
Page 27: Printing Techniques
Printing Techniques Precautions to ensure print quality: 1. Ensure accurate nozzle height. Nozzle too high will cause warping, nozzle too low will crash into platform causing damage and clogging. It is possible to manually fine tune nozzle height value at "maintenance" and "print preview" panels. User could try to adjust the nozzle height value plus or minus 0.1 - 0.2mm base on previous results. -
Page 28: Troubleshooting
Troubleshooting Problems Solution 1.Initialize the printer. Printing or platform cannot 2.Heater catridge is broken, seek replacement. reach target temp or over heat. 3. Cable is broken, replace the cable. 1. Plastic clog the nozzle, replace new nozzle or remove the clog. 2.
