Appendix
System Information Window
Advanced Stats Tab
The Advance Network Statistics screen contains information about the status of a call. It
describes how fast audio and video is coming in and going out during a call. The statistics will
continually refresh throughout the duration of the video call. If the ViewStation is not in a call, the
statistics will appear as dashes.
Global Management System User's Guide
Field
Description
Tx
Audio rate
Audio Rate transmitted
Video rate
Transmitting video rate
Video Rate Used
The actual amount of bandwidth
being used for video data
Video Frame Rate
The current number of video
frames per second
Video FEC Errors
The number of Forward Error
Correction (FEC) errors that have
corrected in the current call
LSD Protocol
The current Low Speed Data
(LSD) channel protocol in use
LSD Rate
The rate used for Low
Speed Data (LSD) channel
communications
MLP Protocol
The current MLP channel
protocol in use
MLP Rate
The rate used for MLP channel
communications
Remote System ID
An identifier string sent by
the remote site (usually a
manufacturer name)
Audio Packet loss
The number of audio packets lost
in transmission
Audio Jitter
The variance from average audio
transmission rate
Video packet loss
The number of video packets lost
in the call
Video Jitter
The variance from average video
transmission rate
ViewStation FX and EX
-
Rx
Receiving Audio rate
Receiving video rate
The actual amount of bandwidth
being used for video data
The current number of video
frames per second
The number of Forward Error
Correction (FEC) errors that have
corrected in the current call
The current Low Speed Data
(LSD) channel protocol in use
The rate used for Low
Speed Data (LSD) channel
communications
The current MLP channel
protocol in use
The rate used for MLP channel
communications
An identifier string sent by
the remote site (usually a
manufacturer name)
The number of receiving audio
packets lost in the call
The variance from average audio
receiving rate
The number of video packets
lost in the call
The variance from average video
transmission rate
Appendix
122
