Polycom GlobalManagementSystem User Manual page 63

Global Directory Configuration
Configuring the server for ILS
1. From the Global Directory window, select the Configuration button. A pop up window will
2. Two tabs are labeled with ILS or LDAP. Select the ILS tab.
3. Enter the following information:
4. Click on Update.
Deleting your configuration settings
If changes have been made to ILS server, select the configuration button. Click on the ILS tab
and then click on delete. The ILS configuration entry will be deleted.
Global Management System User's Guide
appear.
Field
Address
Port
LOGIN
PASSWORD
Description
Name or IP address of server
Use 0 to accept the default protocol
If ILS is from Site Server 3.0, then its port is 389.
If ILS is from Windows 2000, the its port is 1002.
Optional
Optional
Chapter 3 Global Directory 58
