h. Monitor Mode. There are applications which may require FuelMaster
the flow of fuel, but not through individual transactions. Such would be the flow of fuel to a
furnace or some other device which is continually operating. One application uses it to monitor
the continuing flow of water and glycol into a deicing fluid blender. This can be accomplished
through the use of the Monitor Mode.
In the Monitor Mode, no authorization signal is required so nothing needs to be connected to the
Pedestal I/O Board LN and LD positions. FMU firmware activates the relay for the hose put in
Monitor Mode. An LED on the Relay Assembly corresponding to the activated relay will
illuminate steady while in Monitor Mode.
Pulses from a pulser or flowmeter are needed, so connections are made to the Pedestal I/O
Board pulser connectors on J4, J5, J6, and/or J7, as needed. The Monitor Mode monitors
incoming pulses and records a transaction after 10,000 pulses or once per day, whichever
occurs first.
Any of the eight hose positions in the FMU can be configured for the Monitor Mode. Monitor
Mode may be turned on through the use of a laptop connection, or with a Supervisor Prokee
Smartcard. If a Supervisor Prokee
option is to enable all hoses with Monitor Mode. If performed with a laptop connection (or by the
Customer Satisfaction Center), individual hoses may be configured.
Perform the following to configure Monitor Mode:
1) With a laptop connection:
a) Make a laptop connection in accordance with Product Bulletin 111.
b) Use the 54 command to display the Pump Mode Menu.
c) Select the hose position (A-H) to modify by typing the hose letter and depressing Enter.
The Pump Mode Configuration Menu will be displayed.
d) Depress 5. Enable Monitor Mode. The Pump Mode Menu will be displayed and show
the selection of Monitor Mode.
e) Depress <ESC>=Exit. The prompt CONFIGURATION HAS CHANGED. WOULD YOU
LIKE TO SAVE IT? (Y/N) will appear.
f) Depress Y to save the configuration change. The prompt Saving Configuration
Changes... PUMP #__ -> MONITOR MODE ENABLED
displayed.
g) Use the 07 command to exit the laptop connection.
2) With a Supervisor Prokee
a) Insert a Supervisor Prokee
b) Select B=ISSUES. The SUPERVISOR ISSUES MENU will appear.
c) Select B=MODE. The MODE MENU will appear.
d) Select B=MONITOR. The SUPERVISOR MONITOR MODE MENU will appear.
e) Select A=TURN ON. The prompt ALL ACTIVE PUMPS IN SEMI MANUAL MODE –OR-
MONITOR MODE! will appear.
f) Depress D=EXIT to exit the Supervisor menus.
8. Pulse Inputs
AC ground cannot be substituted for 0V in pulser applications.
a. Standard Accessory Pulsers/Pulse Generators. Pulse inputs are necessary to register
quantity. Pulse inputs are made to receptacles J4 (hoses A and B), J6 (hoses C and D), J5
(hoses E and F), and J7 (hoses G and H) located at left center on the Pedestal I/O Board. The
+12V positions are sending 12 VDC to the pulsers. This 12 VDC is constant whenever power is
applied to the FMU, and the FMU power switch is on. The P_ (P1 for hose A, P2 for hose B,
etc.) positions are receiving pulses from the pulsers. The 0V positions are common or ground.
The OK_ (OK1 for hose A, OK2 for hose B, etc.) positions are for 12 VDC pump handle or
