Setting the Setpoint:
1. Type a 57 command and press Enter. A display similar to the following should appear:
CURRENT HIGH FLOW SETPOINTS:
PUMP A: 0.0
PUMP B: 0.0
PUMP C: 0.0
PUMP D: 0.0
ENTER PUMP POSITION TO MODIFY [A-D,<ESC> to EXIT]:
2. At the prompt ENTER PUMP POSITION TO MODIFY [A-H,<ESC> to EXIT]:, enter A to modify the
setpoint for pump position A. A display similar to the following should appear:
CURRENT HIGH FLOW SETPOINTS:
PUMP A: 0.0
PUMP B: 0.0
PUMP C: 0.0
PUMP D: 0.0
ENTER PUMP POSITION TO MODIFY [A-H,<ESC> to EXIT]: A
ENTER NEW HIGH FLOW SETPOINT FOR PUMP A: ____
When the transaction quantity reaches the setpoint value, the fast valve will close and the slow valve will
finish the transaction. Recommend a small value (i.e., 0.2 or 0.3) be tested. Most systems pump very
slow through the slow valve. Some customers may not have the patience to wait through a large setpoint
value.
3.
Enter a small setpoint value for pump A and press Enter. A display similar to the following should
:
appear
ENTER NEW HIGH FLOW SETPOINT FOR PUMP A: 0.3
HIGH FLOW SETPOINT FOR PUMP A SET TO: 0.3
CURRENT HIGH FLOW SETPOINTS:
PUMP A: 0.3
PUMP B: 0.0
PUMP C: 0.0
PUMP D: 0.0
ENTER PUMP POSITION TO MODIFY [A-H,<ESC> to EXIT]: _
4. Repeat steps 2 and 3 for all additional hoses. When complete, press Esc and a display similar to the
following should appear:
CONFIGURATION HAS CHANGED!
WOULD YOU LIKE TO SAVE IT ? (Y/N)
