3) Download transactions and make sure that card record reflects transaction. Mark
NA if not used. Prepaid Prokee record should reflect balance after transaction is
deducted.
p. RECORD TRANSACTION DATA. Perform automated test transactions on each hose.
Record the quantity displayed on the dispenser as DISPENSER QTY. Go to the Central
Controller and download the test transactions and record them under POLLED QTY.
Perform a test transaction and anotate under DISPENSER QTY. Every hose for every FMU
must be tested. Go to Central Controller and either download or query. Compare POLLED
QTY to DISPENSER QTY. Quantities should match.
HOSE DISPENSER
# QTY
1
2
3
4
5
6
7
8
q. SAFETY. Repeat for multiple FMUs. Note any deviations on page 5.
1) FMUs are installed in accordance with the NEC. If mounted in a Class I, Div 2,
location, all electronic components, switches, and relays are located over 18
inches above grade level, and FMU is not installed within 18 inches of a gasoline or
E85 dispenser (or 5 feet from a CNG dispenser). Explain any deviations on page 5.
Any safety or operational deviation must be corrected. Minor (non-safety or operational
related) deviations must be anotated on page 5.
2) All connections at the FMU which are a potential shock hazard are covered and
labeled with appropriate warnings, and located within a locked enclosure. All
standard connection points within the FMU and as directed by this installation manual are
covered, labeled, and within a locked enclosure.
3) An emergency stop switch is present, not within 20 feet nor greater than 100 feet
from the fuel island. When activated, the emergency stop switch removes power
from all fueling site equipment. NEC requirement.
r. POST INSTALLATION INSPECTION. Repeat for multiple FMUs. Note any deviations on
page 5.
1) FMU is securely mounted with four 3/8 inch (minimum) screw anchors/attach bolts.
Pedestal is predrilled for 3/8 inch screw anchors/attach bolts. Syn-Tech uses stainless
steel screw anchors, nuts, and washers.
2) Any entry holes drilled/punched in FMU are sealed. Requirement of equipment
certification.
3) FMU upper cabinet and pedestal door gaskets provide weatherproof seal of
internal components. Required for protection of internal electronic components.
4) FMU upper cabinet is secured to pedestal with six screws. Less than six screws will
not properly seal interface/gasket area.
Installation Manual
®
POLLED HOSE
QTY
10
11
12
13
14
15
16
123
DISPENSER
# QTY
9
POLLED
QTY
