Prokee /Smartcard Encoder
®
The Encoder uses data entered in the Fuel Management
Software to encode, re-encode, or read Prokee
data, and to update Preventive Maintenance or odometer
mileage. The Encoder is available for either USB or parallel
connection to the Central Controller. The parallel connected
Encoder requires a 115 VAC connection for its power supply
where the USB encoder draws its power through the USB
connection. If not otherwise specified, a USB connected encoder
is provided.

Optional Equipment and Taskings

The following optional equipment and taskings (in alphabetic order) are available for use with
FuelMaster , or as a future upgrade:
®

Abierto Gateway Dial-to-IP Converters

internet to gain credit card authorization. It receives an analog phone input from the FMU when it
dials out for credit card authorization, and sends it out to the credit card network via the internet.
An analog phone line is not required, but there is a monthly fee through Abierto Networks for
credit card processing.

AIM

: AIM (Automotive Information Module) is the major component of FuelMaster
system; FMU activation does not require direct user interface. When a fuel nozzle is inserted into
an authorized vehicle's filler neck, the FMU receives an RF (radio frequency) authorization signal
from an AIM in the vehicle. The passive FMU then turns on the applicable dispenser hose. The
passive FMUs are distinguished by two antennas with AIM2™, or two external radios with
AIM2.4™ attached to the upper cabinet. AIM HD (Heavy Duty) permits the AIM module to be
mounted outside the vehicle in the environment. AIM HD is available in both AIM2 or AIM2.4
specifications. A thorough explanation of AIM is covered in the AIM2™ Installation Manual.

Americans with Disabilities Act (ADA):

shortened FMUs for compliance with the requirements of the Americans with Disabilities Act. If you
have a need for an FMU with ADA compliance, speak to your distributor or FuelMaster
Sales Manager. Installation considerations are covered in Section IV.

Automatic Call Processor

comshare device) may be used to share analog phone lines between several devices when only one
analog phone line is available. The Automatic Call Processor receives an input from one analog phone
line. It has a default output which is usually used with a fax machine. Additional outputs are available
and use switching commands to switch the output from the fax machine output to other ports for an
FMU, tank monitor, or any other device requiring an analog phone line.

Credit Card Access

readers which are accessible with most credit and gas cards. An active analog phone line must be
used to acquire credit card authorization for most credit card types (see Local Authorization FMU
Access for other options). A listing of FuelMaster
may be found in Appendix E.
Installation Manual
®
: an Automatic Call Processor (sometimes also referred to as a
: fixed Master FMUs may be equipped with magnetic stripe credit card
30
and Smartcard
®
: the Abierto converter permits the use of the
Syn-Tech Systems has provided and installed
Credit Card Networks (effective 15 May 2013)
®
Figure 2-3.
