The 941B0244 cable has a DB9 serial connector on one end, and loose wires on the other end. On the
loose wire end are red, black, and clear wires for connection to the 5 pin connector on JP11 of the I/O
Silver Board. When splicing cable to extend the 941B0244, the red wire extension must connect to OUT-
(OUT minus). The black wire extension must connect to IN+ (IN plus). The clear wire extension must
connect to GND (ground). The DB9 connector connects to POS 1 on the PIE Controller.
The 952B0103 cable ends are labeled to identify where they connect. If not connected correctly, the
signal from the Quad UART Board will not be properly transmitted to the I/O Silver Board, and the
Electronic Dispenser Interface Kit connection will fail.
952B0103 Cable. The 952B0103 cable connects between SER PORT D of the Quad UART Board, and
JP12 of the I/O Silver Board. The cable has labels near each end to identify which component each end
connects to. If not connected correctly, the signal from the Quad UART Board will not be properly
transmitted to the I/O Silver Board, and the Electronic Dispenser Interface Kit connection will fail.
FMU Configuration
•
FMU and Software Configuration instructions may change with newer firmware or software updates
before changes appear in these instructions. Be sure to reference the FMPlus User Manual to be
certain all instructions are followed.
•
To avoid conflicting instructions, software instructions provided in the FMPlus User Manual will be
noted but not duplicated here.
The FMU must be a Plus FMU utilizing firmware version 3.63d or later. All FuelMaster
Supplied Equipment must be installed and powered before an interface may be made between the FMU
and the electronic dispenser. When the FMU initializes it will self-test the installed Electronic Dispenser
Interface Kit components, and display the self-test remarks shown below in bold face. Other remarks
pertaining to other equipment may appear, and should not be compared to the following:
FMU2500+ ADS-PHILLIPS v3.74a (10/10/12)
NMI POWER ON RESET
COPYRIGHT 2012 SYN-TECH SYSTEMS, INC.
TESTING WATCHDOG TIMER...
WATCHDOG TIMER TEST -- PASSED!
INITIALIZING UARTS...
SECOND QUART BOARD DETECTED!
MULTI INPUT BOARD DETECTED!
SANDISK COMPACT FLASH CARD DETECTED!
SANDISK COMPACT FLASH CARD DETECTED!
TMU INTERFACE ENABLED! (1200,7,E,1)
MAINBOARD CPLD VERSION: 1
INITIALIZING SECONDARY UARTS...
DETECTING ELECTRONIC PUMP CONTROLLER...
ELECTRONIC PUMP CONTROLLER DETECTED!
VEHICLE KEY SYSTEM
INITIALIZING RTIP NETWORK STACK...
INITIALIZING COMPACT FLASH...
INITIALIZING VIRTUAL FILE SYSTEM...
MODEM TYPE: ROCKWELL SOCKET MODEM 33600
CHECKING SYSTEM CONFIGURATION...
