Introduction
Following are procedures for installing a complete FuelMaster
optional equipment. Detailed planning and preparation for these procedures was covered in Section 3,
Site Planning and Preparation.
All the following procedures may not have to be performed, nor may they have to be performed in the
order shown. It is recommended that these procedures be read and applied to each application before
proceeding with any work. If questions arise, contact Syn-Tech's Customer Satisfaction Center (800-888-
9136, ext. 1500) for assistance.
Initialization may be performed in conjunction with Installation. When both operations are being performed
by the same installer, it is recommended the installer spend some time with the customer to setup the
Central Controller, load the software, and perform some Central Controller training prior to progressing to
the other hardware installations. This will permit the customer time to develop the necessary databases
and encode Prokee
®
Unpacking and Inspection
Vibration and rough handling could cause attaching parts to work loose during shipment. Do not
dispose of packing materials until all components listed on the packing list are accounted for.
The FMU is disassembled before shipment and packed in two boxes. The FMU pedestal is packed in a
54" x 18" x 12-1/2" box, and the upper cabinet and accessory materials (i.e., software, encoder, manuals,
Prokee®s, Smartcards, etc.) are packed in a 26" x 19" x 18" box. The components are packed in plastic
bags then placed in the shipping box where a liquid packing foam is injected to protect the components in
shipment. The EIU is shipped in one box 66" x 14" x 14". The EIU Cabinet is separated from the EIU
Pedestal.
The serial number of the components which make up each FMU is written on the outside of the shipping
containers. (Example: "3469"; there will be only one pedestal box, and one upper cabinet box with
matching serial numbers.) In addition, the FMU serial number may be found on the ID plate riveted to the
side of the FMU pedestal, and on a bar code label adhered to the inside of the upper cabinet. The upper
cabinet must be matched to the pedestal to successfully apply an FMU activation code after the
installation is completed and power is applied.
Unpack the boxes and inspect the contents against the packing list. The FMU and accessory material
packing list is affixed to the FMU pedestal box. The EIU packing list is affixed to the single EIU shipping
box. Check for any missing equipment or signs of damage from shipment. Verify the components shown
on the packing list match the customer's requirements. If anything is not correct, it should be noted and
corrected before the installation proceeds. Contact Syn-Tech Systems' Customer Satisfaction Center
(800-888-9136, ext. 1500) as soon as possible if any damage is noted or anything is missing.
FuelMaster
®
Section 4
FMU Installation
s or Smartcards that may be required to test the hardware after installation.
