Syn-Tech Systems FuelMaster FMU-2500 Classic Installation Manual page 126

FuelMaster
5) FMU board/backplate attach screws are secure. Screws holding mainboard and
Satellite I/O Control Board to backplate are secure, and four screws holding backplate
assembly into FMU are secure. Screws (from outside FMU) holding relay assemblies and
Pedestal I/O Board in pedestal are secure.
6) Wire/cable connections are correct and secure. Self-explanatory.
7) Board retainer for mainboard expansion cards is installed and secure. Star washers
have been added to some to keep board retainer screws tight.
5. TRAINING. User was provided training for:
a. How to start a transaction at the FMU, access is dependent upon type of system; may
require Prokee
b. How to use a Supervisor Prokee
spring-loaded contacts; Smartcard must have chip oriented to right
c. How to load and open the software program, doubleclick on icon, enter Operator
Name and Password, click on OK
d. (Software Upgrades Only) New features of upgraded software and/or FMU, explain
differences between old and new software
e. How to download transactions from the FMU to the computer, from main page of
software program, click on Online icon, select Download Options, select site IDs to
download, select Normal Download, click on Connect
f. How to encode a Prokee
properly connected, verify correct information in database, click on Prokee
Prokee
®
g. How to de-authorize a Prokee
User icon, find vehicle or user to de-authorize, unclick Authorized box, send Authorization
List
h. How to re-enable a locked-out hose, from Console, select site, click on Dial, from
Remote Command Menu select 2. Reenable a Pump
i. How to use Price Levels, from Tables, click on Products, open a product from Product
List, cover Base Cost and Price Levels
j. How to use Discount Credit cards and a prepaid Prokee
reference software User Manual
k. Who to call for troubleshooting/training assistance 800-888-9136, ext. 1500
6. DATA
a. Site Signature: Can be found on Packing List, or by clicking on Help/?/System Info in software
b. FMU telephone number: Phone number for FMU modem (if applicable)
c. FMU IP Address: IP address of FMU Network Interface Card (NIC)
d. Network is Cable, Fiber, Wireless (circle one) Circle Cable, Fiber, or Wireless
e. Zlinx Baud Rate/Data Bits/Stop Bits/Parity/Channel: Information needed to be able to send
replacement Zlinx to customer
f. Number of Master FMU's: Self-explanatory
Installation Manual
®
, Smartcard, credit card, keyless, or AIM2™
®
or Smartcard using the Encoder, verify Encoder is
®
or Smartcard in Encoder
or Smartcard, Prokee
®
or Smartcard, in software program, go to Vehicle or
®
124
must be pushed against
®
icon, insert
®
/Smartcard, if applicable,
®
