Syn-Tech received notification of PCI compliance in May 2009. If it is desired to validate compliance
through the PCI Security Standards Council website, go to Validated Payment Applications and
search on Syntech-Fuelmaster.
FuelMaster has also been certified by the National Conference on Weights and Measures, and has
®
NTEP (National Type Evaluation Program) Certificate 02-115. The NTEP certificate applies to the
FMU-2500 and FMU-3000 series, and is referenced on the FMU ID plate. The series covers FMU-
2500 classic and Plus FMUs, and FMU-3000 and FMU-3500 passive FMUs.

ID Plates

An ID plate (see Figure 1-3) is affixed to the side of the FMU pedestal closest to the pedestal door locks.
The ID plate contains the serial number of the unit as well as certification information, and a code to
cross reference the key number used in the door locks (see Table 1-1). If a pedestal is replaced due to
an upgrade or damage, the new pedestal will not have an ID plate installed. Remove the ID plate from
the older unit and install it on the newer unit using pop-rivets. Pop-rivets 1/8 inch wide x 1/4 inch long
should be used to secure the ID plates to the pedestal.
The FMU is shipped in two pieces, in two separate shipping containers. The upper cabinet has a bar
code label inside the cabinet on the side wall closest to the door hinges. The bar code label has the
FMU serial number printed to match the serial number on the pedestal ID plate. The shipping containers
are also marked with the FMU serial number.

WARNINGS, CAUTIONS and NOTES

This manual emphasizes special operations with Warnings, Cautions, or Notes preceding the applicable
procedure:
•
A WARNING indicates a safety precaution that, if not followed, could result in personal injury;
•
A CAUTION indicates a safety precaution that, if not followed, could result in damage to
equipment; and,
•
A NOTE indicates a procedure requiring special emphasis for the proper installation and
operation of FuelMaster
Warnings and Cautions in this manual are provided in both English and French to meet the needs of our
French speaking customers in Canada.
FuelMaster Installation Manual
®
Key Number
300
325
350
375
400
425
450
475
500
523
333
Table 1-1. FMU Door Key Reference
equipment.
®
ID Plate Code
0
1
2
3
4
5
6
7
8
9
10
19
