Syn-Tech Systems FuelMaster FMU-2500 Classic Installation Manual page 203

q. SAFETY. Repeat for multiple FMUs. Note any deviations on page 5.
1) FMUs are installed in accordance with the NEC. If mounted in a Class I, Div 2, location,
all electronic components, switches, and relays are located over 18 inches above grade
level, and FMU is not installed within 18 inches of a gasoline or E85 dispenser (or 5 feet
of a CNG dispenser). Explain any deviations on page 5.
2) All connections at the FMU which are a potential shock hazard are covered and labeled
with appropriate warnings, and located within a locked enclosure.
3) An emergency stop switch is present, not within 20 feet nor greater than 100 feet from
the fuel island. When activated, the emergency stop switch removes power from all
fueling site equipment.
r. POST INSTALLATION INSPECTION. Repeat for multiple FMUs. Note any deviations on
page 5.
1) FMU is securely mounted with four 3/8 inch (minimum) screw anchors/attach bolts.
2) Any entry holes drilled/punched in FMU are sealed.
3) FMU upper cabinet and pedestal door gaskets provide weatherproof seal of internal
components.
4) FMU upper cabinet is secured to pedestal with six screws.
5) FMU board/backplate attach screws are secure.
6) Wire/cable connections are correct and secure.
7) Board retainer for mainboard expansion cards is installed and secure.
5. TRAINING. User was provided training for:
a. How to start a transaction at the FMU,
b. How to use a Supervisor Prokee
c. How to load and open the software program,
d. New features of upgraded software and/or FMU,
e. How to download transactions from the FMU to the computer,
f. How to encode a Prokee
g. How to de-authorize a Prokee
h. How to re-enable a locked-out hose,
i. How to use Price Levels,
j. How to use Discount Credit cards and a prepaid Prokee
k. Who to call for troubleshooting/training assistance.
6. DATA
a. Site Signature:
b. FMU telephone number:
c. FMU IP Address:
d. Network is Cable, Fiber, Wireless (circle one)
e. Zlinx Baud Rate/Data Bits/Stop Bits/Parity/Channel:
or Smartcard,
®
or Smartcard using the Encoder,
®
or Smartcard,
®
Page 4 of 5
/Smartcard,
®
