10.22.2 Set PRNUC Correction

Note
The PRNUC correction function and specific setting method may differ by device models.
The device supports PRNUC (Photo-response Non-Uniformity Correction) function that
eliminates vertical line on the images. Two correction methods are available, including
global correction and ROI correction. The effect of PRNUC correction is shown blow.
Figure 10-42 Before PRNUC Correction
Figure 10-43 After PRNUC Correction
Global PRNUC Correction
For MV-CL021-40GM device, follow steps below to set PRNUC correction:
Steps
1. Click Shading Correction, and click Execute in Activate Shading.
2. Enable NUC Enable, and PRNUC Enable will be enabled automatically.
