Chapter 2 Appearance - HikRobot GigE User Manual

Note
● The device's appearance may differ by device models. The image below is for reference
only. For specific appearance and dimension, please refer to the device's specification
for details.
● The appearance is subject to change, and the actual device you purchased shall prevail.
No. Component
1 Lens Mount
Screw Hole
2
Screw Hole of GigE
3
Interface
4 GigE Interface
LED Indicator
5
6 Power and I/O Connector
GigE Line Scan Camera User Manual

Chapter 2 Appearance

Figure 2-1 Appearance
Table 2-1 Component Description
It is used to install the lens. Refer to the device's
specification for specific lens mount information.
It is used to fix the device to the installation position.
Refer to the device's specification for specific screw
information.
It refers to the M2 screw hole for fixing the network
cable.
It refers to the GigE interface for transmitting data.
It indicates the device's status.
It provides power supply, input/output signal and serial
port function.
Description
2
