HikRobot GigE User Manual page 14

No.
5 GND
6 IO_IN1_P
7 IO_IN1_N
8 IO2
9 IO_OUT0_P
10 IO_OUT0_N
11 IO_OUT1_P
12 IO_OUT1_N
Second Type of Pin Definitions
The second type
MV-CL042-91GM/GC, MV-CL084-91GM, MV-CL086-91GC, and MV-CL024-91GM/GC.
Note
Refer to the table below and the label attached to the power and I/O cable to wire the
device.
No.
1 GND
2 DC_PWR
3 LINE0_P
4 LINE0_N
5 GND
6 LINE3_P
7 LINE3_N
8 LINE4_P
9 LINE1_P
10 LINE1_N
11 DC_PWR
12 LINE4_N
GigE Line Scan Camera User Manual
Signal I/O Signal Source
Line 2-
Line 3+
Line 3-
Line 2+
Line 1+
Line 1-
Line 4+
Line 4-
of pin definitions
Table 3-2 Second Type of Pin Definitions
Signal I/O Signal Source
--
--
Line 0+
Line 0-
--
Line 3+
Line 3-
Line 4+
Line 1+
Line 1-
--
Line 4-
Power supply ground
Differential input IO 1+
Differential input IO 1-
Bi-directional IO
Differential output IO 0+
Differential output IO 0-
Differential output IO 1+
Differential output IO 1-
is applicable
Power supply ground
DC power supply positive
Differential input/output IO 0+
Differential input/output IO 0-
Power supply ground
Differential input/output IO 3+
Differential input/output IO 3-
Differential input/output IO 4+
Differential input/output IO 1+
Differential input/output IO 1-
DC power supply positive
Differential input/output IO 4-
4
Description
to MV-CL022-91GM/GC,
Description
