4.1 Installation Preparation

You need to prepare following accessories before device installation.
No. Name
Power and I/O
1
Cable
DC Power Supply
2
Network Cable
3
4 Lens
5 Lens Adapter

4.2 Install Device

Before You Start
● Make sure that the device in package is in good condition and all assembly parts are
included.
● Make sure that all related devices are powered off during the installation.
Steps
1. Fix the device to the installation position.
2. Install the lens to the device.
3. Use a proper network cable to connect device with a GigE switch or a network interface
card.
4. Select a power supply method:
● Direct power supply: Use the 12-pin power and I/O cable to connect device to a proper
power adapter.
● PoE (Power over Ethernet): For the device that supports PoE, use a network cable to
connect the device to a switch that supports PoE or a network interface card.
GigE Line Scan Camera User Manual

Chapter 4 Installation

Table 4-1 Accessories
Quantity
It refers to the 12-pin power and I/O cable. You need
1
to purchase separately.
You should select suitable power adapter or switch
1 power supply according to the device power supply
and consumption. You need to purchase separately.
It refers to CAT-5e network cable or above. You need
1
to purchase separately.
It refers to the lens that is suitable for the device. You
1
need to purchase separately.
If the lens you used does not match with lens mount
1 of the device, you need to use a lens adapter. You
need to purchase separately.
Description
