Status display

Control icons

34
K
Display icons for using froeling-connect
⇨ See "Display icons for froeling-connect/remote control" [page 35]
L
Brightness sensor for automatically adjusting the brightness of the display
M
Status LED to display the current system status
⇨ See "Status display" [page 34]
N
USB interface for software update, see operating instructions for the boiler controller
The status display indicates the system's operating status:
▪ GREEN flashing (interval: 5 sec OFF, 1 sec. ON): Off
▪ GREEN constant: BOILER SWITCHED ON
▪ ORANGE flashing: WARNING
▪ RED flashing: FAULT
Confirms values entered; activates parameters
Discards any values entered without saving; and closes messages
Back to basic display
Accesses all system information
Opens quick menu. Selection of functions depending on user level, configuration
and current status.
Tap to change parameters (dropdown menu or numeric keypad)
Opens system menu. Menu display depends on user level and configuration
Back to higher menu level.
