4.12.2 Cleaning the combustion grate

4.12.3 Empty the ash drawer of the pellet unit

54
❒ Scrape the ash in the combustion chamber into the ash shovel using the furnace
tool
❒ Scrape the ash from the sides of the combustion chamber into the ash shovel
using the furnace tool
❒ Shovel the ash into the container provided
➥ Use a fire-proof container with cover
❒ Open the fuel loading door and remove the combustion grate
❒ Remove ash deposits from the combustion grate and secondary air inlets (A)
❒ Open the insulated door to the pellet unit
❒ Push the locking lever down and pull out the ashcan
❒ Hang the transport hook opposite the locking lever, take the ashcan to the
emptying point and empty it
